Aeolos is our best selling integrated amplifier. It offers everything the user needs in a compact and classic design. The push – pull configuration draws enough power from the output tubes to drive most loudspeakers.
Gold plated RCA connectors are implemented for the signal inputs/output and WBT-0710 Next Gen binding posts for the loudspeakers.
For the volume control the classic blue Alps is used.
An elegant remote control in aluminum case offers you control over all the functions of Aeolos integrated amplifier. Volume control, input selection, mute and power tubes bias mode.
Inputs: 4 line inputs
Outputs: 1 pre output
Input selection: High grade signal relays
Input/Output connectors: RCA gold plated
Speaker connectors: WBT-0710 Next Gen
Remote control: Yes
Volume control: Blue Alps
Power supply capacitors: United Chemicon 105oC
Signal capacitors: Mundorf Supreme Silver Gold Oil capacitors
Power resistors: Metal film 5% tolerance
Low power resistors: Metal film 1% tolerance
Power transformer: Handmade 400W
Output transformer: Handmade 16 layer 6N copper high quality core
Driving stage tubes: 4x12AT7
Power tubes: 4xKT150
Output Power: 2x70W
Input impedance: 100 kOhm
Output impedance: 6 Ohm
Input sensitivity: 350mV
Signal to Noise Ratio (SNR): 88db
Channel separation: 68db
Rise time: 4us @ 10kHz
Harmonic distortion: 10W @ 1kHz 0.35%
Frequency response: -3db 3Hz-84000Hz
Power supply energy: 200Joule
Power consumption: 220W
Weight: 23kgr
Dimensions (WxDxH): (29x46x23)cm
