TEAC UD-701N

€3,699.00

With a newly-developed original discrete DAC, this advanced all-around unit fascinates every audiophile as the core of an audio system.

With USB DAC functions as the foundation, a network player, an analog preamp, a headphone amplifier and various other functions have been combined at a high level. This TEAC flagship with a newly-developed TEAC ΔΣ (Delta Sigma) discrete DAC has achieved a new level.

As a USB DAC and network player, 22.5MHz DSD and 384kHz/32-bit PCM are supported. Using the newly-developed TEAC ΔΣ discrete DAC, all digital signals are converted to analog signals with high audio quality.


Not only can this be used for all kinds of digital playback, from systems centered on a PC or Mac to audio server systems using NAS and streaming playback, it can also fulfill a core role in systems as a preamp with analog and digital inputs. The UD-701N is an all-around unit that flexibly supports new listening styles in a new age. Along with allowing listening through speakers in combination with a power amplifier, it also supports balanced headphone output using a 4-pin XLR jack.

Spec description

DAC section DACTEAC ΔΣ Discrete DAC × 2Upconvert2xFs / 4xFs / 8xFs (maximum 384kHz)

Analog audio inputs Balanced ConnectorsXLR × 1 pairInput impedance50kΩMaximum input level5VrmsUnbalanced ConnectorsRCA Pin (gold-plated) × 1 pairInput impedance25kΩMaximum input level2.5Vrms

Digital audio inputs USB ConnectorsUSB B-type × 1, (USB2.0 compliant)Supported formats PCM16 / 24 / 32bit
44.1k / 48k / 88.2k / 96k / 176.4k / 192k / 352.8k / 384kHzDSD2.8M / 5.6M / 11.2M / 22.5MHz

Coaxial ConnectorsRCA Pin (god-plated) × 2 pairsInput level0.5Vp-pInput impedance75ΩSupported formats PCM16 / 24bit
32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHzDSD2.8MHz (176.4kHz/24bit DoP format)

Optical ConnectorsRectangular (TOS) × 2 pairsInput level–24.0 to –14.5dBm peakSupported formats PCM16 / 24bit
32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHzDSD2.8MHz (176.4kHz/24bit DoP format)

ETHERNET ConnectorRJ-45 × 1 (1000Base-T)Supported formats PCM16 / 24 / 32bit
32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHz / 352.8k / 384kHz (Stereo)DSD2.8M / 5.6M / 11.2M / 22.5MHz (Stereo)Supported formats PCM losslessFLAC, Apple Lossless (ALAC), WAV, AIFF, MQADSD losslessDSF, DSDIFF (DFF), DoPCompressed audioMP3, AAC (m4a container)USB flash drive ConnectorsUSB A-type × 2 (Front × 1, Rear × 1, USB2.0 compliant)Supported file systemFAT32, exFAT and NTFS single partationSupported file format PCM16 / 24 / 32bit
32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHz / 352.8k / 384kHz (Stereo)DSD2.8M / 5.6M / 11.2M / 22.5MHz (Stereo)Supported file formats PCM losslessFLAC, Apple Lossless (ALAC), WAV, AIFF, MQADSD losslessDSF, DSDIFF (DFF), DoPCompressed audioMP3, AAC (m4a container)Bluetooth® Bluetooth® version4.2Output classClass2 (rrange: 10m)Supported profileA2DP, AVRCPSupported A2DP codecLDAC, LHDC, AAC, SBC, Qualcomm®aptX™ audio/HD audioA2DP content protectionSCMS-TNumber of saved pairingsMaximum 8

Analog audio outputs Balanced ConnectorsXLR (gold-plated pins) × 1 pairOutput impedance220ΩOutput level settingsSelectable from Fixed (0dB), Fixed (+6dB), Variable, or OffMaximum output level2.0Vrms (1kHz, Full-scale, 10kΩ loaded, FIxed at 0dB)
4.0Vrms (1kHz, Full-scale, 10kΩ loaded, FIxed at +6dB)
12Vrms (1kHz, Full-scale, 10kΩ loaded, Variable)Unbalanced ConnectorsRCA Pin (gold-plated) × 1 pairOutput impedance180ΩOutput level settingsSelectable from Fixed (0dB), Fixed (+6dB), Variable, or OffMaximum output level2.0Vrms (1kHz, Full-scale, 10kΩ loaded, FIxed at 0dB)
4.0Vrms (1kHz, Full-scale, 10kΩ laoded, Fixed at +6dB)
6.0Vrms (1kHz, Full-scale, 10kΩ loaded, Variable)

Headphone outputs Balanced Connector4-pin XLR × 1Pin asignPin1: L+, Pin2: L–, Pin3: R+, Pin4: R–

Unbalanced Connector6.3mm Stereo jack (gold-plate) × 1

Maximum output power Balanced700mW + 700mW (32Ω loaded)Unbalanced500mW + 500mW (32Ω × 1 loaded)Supported impedance16 to 600Ω

Clock sync input ConnectorBNC (gold-plated) × 1Input frequency10MHzInput impedance50ΩInput level Rectangle waveEquivalent to TTLSine wave0.5 to 1.0Vrms

External control Trigger Input (12V TRIGGER IN) Connector3.5mm Mono mini jack × 1Input level12V, 1mA

Trigger output (12V TRIGGER THRU) Connector3.5mm Mono mini jack × 1Output level12VMaximum current supply100mA

Audio performance*Measurement conditions: Input signal: 192kHz/24-bit PCM, Measurement output: RCA, DAC low-pass filter: OnFrequency response5Hz to 80,000Hz (+1dB/–5dB)Total harmonic distortion0.002%S/N ratio108dB (A-Weight, 1kHz)Power  AC120V, 60Hz AC220 - 240V, 50/60Hz

Power consumption40WStandby power0.4W

Overall dimensions444 (W) × 111 (H) × 334 (D) mm (including protrusions)

Weight11.8kg

Operating Temperature＋5℃ to ＋35℃

Operating Humidity Range5% to 85% (no condensation)

Storage Temperature Range–20℃ to ＋55℃

Included accessoryPower cord, Remote control (RC-1330), AAA batteries × 2, Owner's manual, Foot pad x 3
